To have access to the Grafcet programming editor, you firstly have to program the logical conditions (receptivities)
For executing a self-consistent procedure for the layout of the Grafcet, it is advised to proceed in the order described below :
1) Placing the steps on the work area
2) Making the layout of oriented connections
3) Placing the receptivity on a connection, this receptivity is indicated by a scroll down list
4) Associating the conditions to the receptivities
5) Associating the actions to the steps
When proceeding with the order 1, 2 and 3 described above, the software checks the validity of the location of the receptivities to ensure self-consistence.
Each one of the steps mentioned above will be discussed in the following pages.
Remark :
